Fiberglass Filter Media
Fiberglass Filter Media

Fiberglass Filter Media

ltem No.: PA-100

It is suitable for paint mist, filters, spray booth and painting room.

Characteristic

  • The fluffy structure with good elasticity can maintain no deformation even under pressure so that all the space of the filter material is fully utilized to collect paint mist and sticky dust
  • The high-strength glass fiber is incremental structure, the air inlet side(green)has a fluffy structure. Along the air outlet side (white), the fiber density gradually increases.
  • Due to its excellent fluffy progressive structure, the surface of the filter material can be prevented from being blocked, and holding paint.
  • It has good corrosion resistance, resistance to various solvents, acid and alkali resistance, and high temperature resistance.
  • The outer frame can be matched with paper frame and galvanized frame or aluminum frame.

Get A Free Quote

after-salesWe have a complete after-sales system

Free Sample

Fully Customized

Low MOQ: 100Pcs

Distribute Globally

Application:

It is suitable for paint mist, filters, spray booth and painting room.

Technical Data

We Support Personalization! To make customized sizes and thicknesses is available.

Model PA-50/60 PA-100
Thickness (mm) 50/60 100
Weight (g/㎡) 240 320
Wind Velocity Test (m/s) 0.7-1.5 0.7-1.5
Initial Resistance (Pa) 15 20
Final Resistance (Pa) 250 280
Temperature Resistance (℃) 170 170
Dust Holding Capacity (g/㎡) 3200-3600 3600-4900
Average Weight Efficiency 93% 96%
